Note:All our products can be customized, if you need better configuration, or other special requirements, please consult our
staff.
1.Bottom frame feet | 2.Underframe secondary beam (100 * 50 * 2.5 rectangular steel) | 3.Bottom frame long side beam (5635mm) | ||||
4.Cement fiber board (19mm) | 5.2mm PVC Carpet | 6.Column trim (2600mm) | ||||
7.Prism （2535mm） | 8. Aluminum alloy hollow tempered glass [1.4 Aluminum alloy 5+9+5 hollow tempered glass] | 9.Ceiling plate 0.5mm V-830 profiled steel plate | ||||
10.Class A fireproof glass wool | 11. skin panel (0.45mm) | 12.Top frame secondary beam | ||||
13.Top frame long side beam (5635mm) | 14.Top frame feet | 15.Top frame short side beam （2690mm） | ||||
16.Top tie beam square tube | 17.Top frame long side beam (5635mm) | 18.Prism （2535mm） | ||||
19.Drain pipe | 20.wall panel （75mm） | 21.PVC baseboard | ||||
22.Bottom tie beam square tube | 23.Bottom frame short side (2690mm) | |||||
